| inner dimension | 5900 × 23 00 × 250 0 mm (L × W × H) |
| outer dimension | 6000 × 2400 × 29 00 mm (L × W × H) |
| Left air inlet operation box | 4800 × 80 0 × 290 0 mm (L × W × H) |
Right exhaust filter box | 4800 × 80 0 × 290 0 mm (L × W × H) |
| Basement | 50x50x2.0 square tube support frame, covered with pattern board |
Direct front to rear doors | Door size: 2100 × 22 00mm (W×H), sheet metal bending door, 2 door
leaves, square tempered glass window, filling: EPS. (The filling
can be adjusted according to needs) |
| main structure | Container corner fittings + 4mm steel plate bent horizontal and
longitudinal beams are welded and formed, and the surface is
sprayed with outdoor anti-rust paint |
Air inlet operation box structure | 50x50 square tube welded frame, 50mm thick EPS wall installed on
the outside, 500x1000 tempered glass windows installed on each wall
panel; casters with brakes installed on the bottom, can be freely
moved and assembled |
| Exhaust filter box structure | 50x50 square tube welded frame, 50mm thick EPS wall installed on
the outside, 1000mm high paint mist filter paper and a layer of
fiberglass cotton installed, which can be freely moved and
assembled |
| working door | 2 sets, working door size: 700×2000mm (W×H), equipped with pressure
lock, glass observation window ; installed at the front and rear of
the left air inlet operation box |
| wall panel | EPS wall panel, effective width 1150mm, total thickness 50mm ,
color steel plate thickness: 0.426mm, white, steel edges sealed on
both sides; ( Rock wool, PU optional ) |
| roof | EPS wall panel, effective width 1150mm, total thickness 50mm ,
color steel plate thickness: 0.426mm, white, steel edges sealed on
both sides; ( rock wool, PU optional ) top waterproof treatment; |
| illumination | Top lighting: 8 groups × 4 pcs = 32 pcs 18W lamps Illumination ≥800Lux |
Make-up air unit | 2 exhaust fans, single motor power: 0.55KW; total flow: 20000m3 /h,
no-load wind speed: 0.25m/s; air supply manual adjustment damper . |
Exhaust air unit | 1 single-inlet axial flow fan, single motor power: 4KW; total flow:
20000m3 /h, no-load wind speed: 0.25m/s; exhaust manual adjustment
damper . |
| Heating system | No heating system |
| filtering system | 1. Air supply primary filter cotton : EN 779 level: G3 2 Glass fiber paint-resistant cotton blanket filtration: EN 779
Level: G3; 3Paint mist filter paper : EN 779 Level: G3; |
Electronic control system | Spray paint, lighting switch, fault indicator light, temperature
controller, power switch, emergency stop switch, timer, pressure
gauge, pressure alarm |
Pipeline system
| The air supply and exhaust are each equipped with 3 sections of 7
00 x 7 00 x 1000mm straight air ducts, 1 section of 700 x 700mm 90°
elbow, and 1 section of 800 x 800mm 45° elbow; |
| Total power | 8KW |
